Labelmate Adjustable Core Holder for TWIN-CAT-3 Rewind Stations - ACH-TC3

Adjustable Core Holder for TWIN-CAT-3 Rewind Stations.

• Core Diameter: 1" - 4"Adjustable (25-101mm)
• Max. Media Width: 6” (152mm)
• Max. Roll Weight: 17 lbs (8 kg)
• Mounting: Setscrew, press fit
• Mounting Hole Diameter: 0.626”
• Mounting Hole Depth: 1.33” (34mm)
• Composition: Steel and Anodized Aluminum
• Warranty: 3 Year Parts and Labor Limited Warranty

Description

Adjustable Core Holder for 1” - 4” diameter cores (25 - 101mm). Interchangeable with QUICK-CHUCK Core-Holders and STANDARD Shafts. Fits precisely on a 0.625” (15.875mm) diameter motor shaft. A setscrew affixes the Core-Holder firmly onto the flat of the motor shaft.

Outer Guide Assembly to maintain flush roll edge purchased separately.
